PRODUCT
40TAC72BDBDC10PN7A NSK
Model No. 40TAC72BDBDC10PN7A NSK
Type : Super Precision Spindle Bearings
Size: 40x72x45mm
Weight: 0.825KG
Datasheet and drawing can be offered.
Stock available for fast delivery,contact me for a quick quotation
Sales Director :arya
Email: arya@bearing-sun.com
40TAC72BDBDC10PN7A NSK
the 40TAC72BDBDC10PN7A bearing is a high-precision thrust angular contact ball bearing with an inner diameter of 40 mm, an outer diameter of 72 mm, and a double-row back-to-back combination. It has standard preload and high precision, making it suitable for applications requiring high accuracy and stiffness, such as machine tool spindles.
Suffix means :
- B High Capacity & Higher Speed (Replaces “A” Type)
- DBD Three Row Combination
- PN7A Represents a special management accuracy for the difference in inner and outer diameter dimensions. It is equivalent to ISO 4 class precision, suitable for multi-row combinations
Please feel free to email me if you are interested .arya@bearing-sun.com
Drawing & Size
| Model No. | 40TAC72BDBDC10PN7A NSK |
| Type | Super Precision Spindle Bearings |
| d | 40 mm |
| D | 72 mm |
| B | 45 mm |
| Weight | 0.825 KG |
Below same series bearings are recommended
| Model No. | d mm | D mm | B mm |
| 15TAC 47B | 15 | 47 | 15 |
| 17TAC 47B | 17 | 47 | 15 |
| 20TAC 47B | 20 | 47 | 15 |
| 25TAC 62B | 25 | 62 | 15 |
| 30TAC 62B | 30 | 62 | 15 |
| 35TAC 72B | 35 | 72 | 15 |
| 40TAC 72B | 40 | 72 | 15 |
| 40TAC 90B | 40 | 90 | 20 |
| 45TAC 75B | 45 | 75 | 15 |
| 45TAC 100B | 45 | 100 | 20 |
| 50TAC 100B | 50 | 100 | 20 |
| 55TAC 100B | 55 | 100 | 20 |
| 55TAC 120B | 55 | 120 | 20 |
| 60TAC 120B | 60 | 120 | 20 |
