Automotive Wheel Bearing DAC 3874 W-6CS84
Automotive Wheel Bearing DAC 3874 W-6CS84

Automotive Wheel Bearing DAC 3874 W-6CS84

Product ID : DAC 3874 W-6CS84
Product Attributes :

Automotive wheel bearing DAC 3874 W-6CS84,

Dimensions: 37.99x74.02x36mm

Datasheets and drawings can be offered.

They are stock available for fast delivery.

If you want to know more about DAC 3874 W-6CS84 bearing, email: alita@bearing-sun.com

Product Description

The main role of the wheel hub bearing is to load and provide precise guidance for the rotation of the hub, it bears both the axial load and radial load, which is a very important part. The wheel bearing unit is developed on the basis of the standard angular contact ball bearings and tapered roller bearings. It combines two sets of bearings as a whole, so it has good assembly performance, can be omitted clearance adjustment, lightweight, compact structure, and load capacity Large, for the seal bearing can be pre-loaded grease, omit the external hub seal and from maintenance, etc., It has been widely used in cars and it also gradually expand the application of the trend in the truck area.



Data sheet and drawing:

1



Type

Automotive bearings

Model

DAC 3874 W-6CS84

d

37.99 mm

D

74.02 mm

B

36 mm

C

33 mm

Mass

0.591 kg



A similar type of bearings in stock:

Item

Wheel hub bearing OE code

Wheel hub bearing model

dimension(mm)

TOYOTA series Applicable models

01

90369-28006

28BWD01

28x61x42

E8,E9,E7

02

90080-36001

30BWD01

30x63x42

V1,V2,T15,T16,T17,T18

03

90369-35029

35BWD07

35x68x33x30

P7,P8,EP91

04

90369-36008

83B169A

36x67x29

PASEO 1991-1999 COROLLA TERCEL 1993-1999

05

90080-36021

43BWD06

43x82x45

V1,V10,V20,V30,MPV,XM10

06

44300-S3V-A01

DAC4889W

48x89x44

KA7,KA8,KA9

07

90043-63187-000

38BWD21

38x70x38

A101,A111,G100,G101,G102

08

90369-35034

DAC3577W-3

35x77x42

JZA80,MA70,UCF10,UCF20

09

90369-38021

38BWD22

38x71x39

CP10,NC/LP2

10

7T41-1215BA

45BWD10

45x84x45

CAMRY V20,V30 ACR3 RX

11

90369-40066

40BWD12

40x74x42

CELICA 2000-2005 MATRIX 2003-2006

12

90369-43005

43BWD03

43x80x50x45

JZA80,MA70 JZS147,UCF10

13

90369-54001

DU5496

54x96x51

SUV J9

14

90363-35016

35BWD06

35x72x33x31

L1,L2 AL2

15

90369-38006

38BWD09

38x71x33x30

PASEO 1991-1999 COROLLA TERCEL1993-1999

16

90369-35060

DAC3580WHR4

35x80x47

PREVIA 1991-1997 MPV ACR3

17

90369-38010

38BWD12

38x72x36x33

E9,E10

18

90369-35001

DAC357245CW

35x72x45

COROLLAAE86 1983-1987

19

90903-64002

38BWD18

38x80x36x 33

CELICA ST205 1994

20

90369-49002

49BWD02A

49x84x50

CROWN

21

90369-50Y00

38BWD01

38x74x36x33

CAMRY V1,V2 MR2 W1

22

90369-43007

46T090804

43x77x42x38

MPV TCR1,2

23

90369-40068

DG4090

40*90*28/23

Toyota

24

90369-40071

DG409426

40*94*31/26

Toyota

25

90369-35061

DG3580

35*80*28/21

S1,S2,TCR1

26

42423-20010

DG409023

40*90*23

Toyota

27

90363-36001

DG366723

36*67*23

Toyota SXV10/ST191

28

90369-45006/A0002

DAC4586WCS69

45*86*45

Toyota

29

90363-40080

40BWD17

40*75*39

Toyota

30

90366-T0044

42KWD10

42*82*40

Toyota



Shipping ways:
1)Total weight less than 45kg, ship by express door to door. (DHL, TNT, FEDEX, UPS, ARAMEX)
In Asian countries, it will take about 4 days.
To European countries, it will take about 5 days.
To North American countries, it will take about 5 days.
To South American countries, it will take about 6 days.
In African countries, it will take about 6 days.
2) Total weight of more than 45kg, less than 200kg, ship by air. It will take about 5-7 days.
3) Total weight of more than 200kg, ship by sea. (cheapest way) It will take about 25-35 days.



Our advantage:

1. Large stock for quick delivery

2. Free gifts for old customers every year

3. Support 7-dayS refund

4.24h*7 days customer service
